Double coiled spring concealed in the leadrail, expands and contracts as the blind opens and closes to ensure a taut fabric at every position.

Hi-tensile dyneema cables run within the side guides and keep the leadrail spring and subsequently fabric under optimum tension.

Healthy & happy living spaces require efficient shading.

Double coiled spring concealed in the leadrail, expands and contracts as the blind opens and closes to ensure a taut fabric at every position.

Hi-tensile dyneema cables run within the side guides and keep the leadrail spring and subsequently fabric under optimum tension.

Healthy & happy living spaces require efficient shading.

EXTERNAL ROOF BLINDS

How our tensioned external roof blinds work

An external roof blind has a similar construction to outdoor roller blinds featuring a cassette headbox to the top and guides to each side but uses a tensioning system to work on all angles for both horizontal and sloping glass.

A rollertube with integrated tubular motor and to which the fabric is rolled around is contained inside the headbox and features a spindle to each end. These spindles have hi-tensile Dyneema cables wound around them which subsequently run down each side guide, over a series of pulleys and into the leadrail, which the fabric is attached to. The cables put under tension a double coiled spring in the leadrail which keeps the blind fabric taut at every position even allowing it to work from bottom up. The leadrail is located and runs within the side guides ensuring the blind runs square and smoothly every operation.

The guides to each side are attached through face fix or side fix brackets to the structure the blind is covering, whether a rooflight frame, conservatory roof glazing bar or pergola beam and the headbox is self-supported through a lug mechanism on the side guides, requiring no physical attachment. The cassette headbox is in two parts with the top section (lid) easily removed to allow for any maintenance or remedial of the blind in situ.

The motor is radio controlled from either a remote control or wire-free wall switched and can be connected to sensors that allows the blind to think for itself, automatically positioning itself based on the suns intensity and wind.

External Roof Blind Models

Cayman Blind

  • Full cassette headbox
  • Up to 5m wide x 6m depth (max 18m/2)
  • Slim guides with concealed tensioning system
  • 100’s of hardware colours & fabric choices
  • Motorised remote / app control operation
  • Sun & wind sensors (optional)
  • Face and side fix mounting brackets
  • Wind resistant upto 24mph (Beaufort 5)
  • From £3,490 inc vat, installation & 5 year guarantee
Find out More
