PERGOLA AWNINGS
A pergola awning is a retractable garden awning that extends out on a framework and can subsequently cover larger areas along with being more rigid and durable than a folding arm awning. Like a folding arm awning, fabric is wound round a rollertube inside cassette headbox, with the fabric connected to the leadrail that extends and retracts with the awning. The fabric is kept under optimum tension at each position by a combination of a double coiled spring inside the leadrail attached to and put under tension via hi-tensile belts concealed in each side guide that connect back to the rollertube. Additionally, the fabric is locked in the guides to each side thanks to a ziplock mechanism which gives further durability in windy conditions.
Thanks to the fabric being locked within the side guides along with an integrated guttering within the leadrail, water runs down the fabric and out a punched slot to the left and right side of the leadrail which conveniently lines up with a hopper on each of the post uprights ensuring water evacuates into and out of the base of the post uprights and doesn’t splash on the terrace.
The full cassette headbox conceals the fabric when the pergola awning is not in use and is cleverly designed with a lid that unhinges to allow for any maintenance or remedial requirements in the future. The slim pergola framework elegantly frames the outdoor space, whilst optional support beams, that span between the guides provide additional rigidity in exposed locations and can also contain LED lighting.
Fixing brackets that are concealed behind the awning cassette allow a safe installation to load-bearing facades, whilst the front posts attach to almost all ground surface from patios to decking through a concealed galvanised steel foot. Bespoke brackets and even goal post frameworks can be designed and produced to allow our pergola awnings to be installed in all applications, even freestanding away from a building.
Pergola Awning Models
Puerto Rico Awning
- Full cassette casing with multi fixing points
- Up to 6m wide x 4.5m outward projection
- 100’s of hardware colours & fabric designs
- Motorised remote / app control operation
- Wind & sun sensors (optional)
- Optional LED lighting & infra-red heating
- Standard and bespoke mounting brackets
- Wind resistant upto 31mph (Beaufort 6)
- From £6,950 inc vat, installation & 5 year guarantee
